Day3 - Vert.x Dagger PoC

blog-image
Credit: Photo by Christian Wiediger on Unsplash

Dagger / Vert.x

In this post I want to show a proof of concept project that makes use of Eclipse Vert.x 4.0.3 and Dagger 2.35.1 dependency injection. The PoC project contains a modularized Vert.x application that is using Maven modules and dependency injection. Vert.x is a project which provides libraries that can be used to create reactive applications on the JVM. The PoC contains a simple HTTP server.

Next I’ll walk you through the individual maven modules starting with the API and at the end we’ll reach the main method that starts the example project.

API

The api module contains the API classes of the application which have no Vert.x dependency. In this PoC it contains the ServerOption POJO and RESTServer interface which will be implemented within the rest maven module.

RESTServer.java
public interface RESTServer {

	Completable start();

	Completable stop();
}

The server interface is very simple. It only defines the start and stop methods. We’ll implement this interface in the rest module.

BOM

The bom module is used to manage the application maven dependency versions. Using a BOM is a good practice when working with a multi-module maven project. It lists dagger, vert.x, project and test dependencies that are needed for the project.

Other module pom.xml files contain the needed dependencyManagement section to import the BOM dependency definitions.

Modules like common, rest, api and server which make use of this do not need to specify the dependency version in the dependencies section.

pom.xml
…
<dependencyManagement>
    <dependencies>
        <dependency>
            <groupId>io.metaloom.poc</groupId>
            <artifactId>poc-vertx-dagger-bom</artifactId>
            <version>${project.version}</version>
            <type>pom</type>
            <scope>import</scope>
        </dependency>
    </dependencies>
</dependencyManagement>
…

Common

The common module is the first module which makes use of dagger.

Dependencies

It thus contains the following dependencies:

pom.xml
…
<dependency>
    <groupId>com.google.dagger</groupId>
    <artifactId>dagger</artifactId>
</dependency>
<dependency>
    <groupId>com.google.dagger</groupId>
    <artifactId>dagger-compiler</artifactId>
    <optional>true</optional>
</dependency>
…

The first dependency provides the dagger annotations that can be used within the code.

The second dependency is used for the maven-compiler-plugin.

Compile Time DI

Dagger does not handle dependency injection during runtime like this is typically done for DI libraries like Guice or Spring DI.

Instead of runtime DI dagger will use compile-time DI. This means that the needed DI code is generated during the compilation of the project.

The dagger-compiler dependency thus needs to be added to the maven-compile-plugin. This will enable annotation processing for the compiler that generates new sources that are needed for the dependency injection mechanism.

pom.xml
…
<plugin>
    <groupId>org.apache.maven.plugins</groupId>
    <artifactId>maven-compiler-plugin</artifactId>
    <configuration>
        <forceJavacCompilerUse>true</forceJavacCompilerUse>
        <verbose>false</verbose>
        <compilerVersion>11</compilerVersion>
        <source>11</source>
        <target>11</target>
    </configuration>
    <dependencies>
        <dependency>
            <groupId>com.google.dagger</groupId>
            <artifactId>dagger-compiler</artifactId>
            <version>${dagger.version}</version>
            <optional>true</optional>
        </dependency>
    </dependencies>
</plugin>
…
When using Eclipse IDE you want to install the m2e-apt plugin to enable processing within the IDE. See SO for details.

Vert.x + Dagger

Next we need to tell dagger how to provide Vert.x dependencies when they are requested in other modules.

In this PoC I choose to create a dagger module which is a class that defines how to provide needed non-dagger dependencies.

VertxModule.java
…
@Module
public class VertxModule {

	@Provides
	@Singleton
	public Vertx vertx() {
		return Vertx.vertx();
	}

	@Provides
	@Singleton
	public io.vertx.reactivex.core.Vertx rxVertx(Vertx vertx) {
		return new io.vertx.reactivex.core.Vertx(vertx);
	}
…

Since the Vert.x instance itself should only be instantiated once we use the @Singleton annotation on the vertx method.

I also added a reactive rxVertx(…) variant to the module. We can request the non-rx variant of Vert.x via the argument of the method since we have already made it injectable via the vertx() method.

The PoC also makes use of Vert.x Web which provides additional functionality for HTTP handling.

VertxWebModule.java
@Module
public class VertxWebModule {

	@Provides
	public Router rxRouter(Vertx rxVertx) {
		return Router.router(rxVertx);
	}

}

The VertxWebModule contains a single method to provide the needed reactive variant of the Vert.x Web Router. Note the lack of the @Singleton annotation. This will make it possible to inject new instances of the router across the application. Sometimes it can be useful to create multiple routers (e.g. for multiple API servers or subrouting)

REST

We now have our RESTServer interface and made Vert.x injectable. Now we can implement the server.

RESTServerImpl.java
@Singleton
public class RESTServerImpl implements RESTServer {

	private final HttpServer rxHttpServer;
	private final Router rxRouter;

	@Inject
	public RESTServerImpl(HttpServer rxHttpServer, Provider<Router> rxRouterProvider) {
		this.rxHttpServer = rxHttpServer;
		this.rxRouter = rxRouterProvider.get();
	}

	@Override
	public Completable start() {
		rxRouter.route("/hello").handler(rc -> {
			rc.response().end("world");
		});
		return rxHttpServer
			.requestHandler(rxRouter)
			.rxListen()
			.toCompletable();
	}

	@Override
	public Completable stop() {
		return rxHttpServer.rxClose();
	}

}

The RESTServerImpl injects the needed dependencies via the constructor. It is also possible to inject dependencies into fields but those need to be set to public. The benefit of using dagger is also that you write code which is easier to be used in combination with mocking frameworks. This is at least my experience.

Since we omitted the @Singleton annotation for the provider of Router we now need to inject the dependency using a Provider. This allows us to invoke the get method which will in turn create a new instance of the Router.

The implementation of the start, stop method follows the basic Vert.x Web server usage.

Server

We now have the REST implementation, Vert.x DI and API. Now we need to create a Dagger component to prepare the dependency graph.

Dagger Component

The Component is the main entry point of a dagger dependency setup. It defines the list of modules which provide injectable dependencies.

ServerComponent.java
@Singleton
@Component(modules = { VertxModule.class, PocBindModule.class })
public interface ServerComponent {

	RESTServer restServer();

	/**
	 * Builder for the main dagger component.
	 */
	@Component.Builder
	interface Builder {

		/**
		 * Inject the options.
		 *
		 * @param options
		 * @return
		 */
		@BindsInstance
		Builder configuration(ServerOption options);

		/**
		 * Build the component.
		 *
		 * @return
		 */
		ServerComponent build();
	}

}

The @Component(modules = { VertxModule.class, PocBindModule.class }) line defines the dagger modules that need to be used.

Dependencies can however also be injected from outside of the dagger dependency mechanism. This is done using the Component.Builder and the @BindsInstance method. Later we’ll see how to create the DI graph and this definition will allow us to inject the ServerOption POJO from outside of the the whole dagger DI mechanism.

Bind Module

The second module we have not yet seen is the PocBindModule. This module now tells dagger what implementation should be used when a RESTServer should be injected.

This injection is actually implicitly being done within the ServerComponent interface by adding the method RESTServer restServer();.

PocBindModule.java
@Module
public abstract class PocBindModule {

	@Binds
	abstract RESTServer bindRESTServer(RESTServerImpl e);
}
The bind module would not be needed when directly injecting RESTServerImpl but I recommend to inject interfaces instead to keep the code clean.

Main Method

Finally we can now create the runner for our PoC.

ServerRunner.java
public class ServerRunner {

	public static void main(String[] args) {
		ServerOption options = new ServerOption();
		options.setPort(8888);

		// Inject the options and build the dagger dependency graph
		ServerComponent serverComponent = DaggerServerComponent
			.builder()
			.configuration(options)
			.build();

		// Start the server
		serverComponent.restServer().start().subscribe(() -> {
			System.out.println("REST server started");
			System.out.println("Now connect to http://localhost:8888/hello");
		}, err -> {
			err.printStackTrace();
		});
	}
}

The DaggerServerComponent class will be auto-generated by dagger and contains the builder which we defined in the ServerComponent interface. The builder contains the configuration method which is used to inject the ServerOption which was instantiated outside of the Dagger scope.

Since we defined the restServer method in the interface of the component we can now access the instance via serverComponent.restServer().

Shading

Lastly I want to point out that the server maven module contains the maven-shade-plugin which will generated a fatjar that can be executed after building the project.

pom.xml
…
<plugin>
    <groupId>org.apache.maven.plugins</groupId>
    <artifactId>maven-shade-plugin</artifactId>
    <executions>
        <!-- Run shade goal on package phase -->
        <execution>
            <phase>package</phase>
            <goals>
                <goal>shade</goal>
            </goals>
            <configuration>
                <filters>
                    <filter>
                        <artifact>*:*</artifact>
                        <excludes>
                            <exclude>META-INF/*.SF</exclude>
                            <exclude>META-INF/*.DSA</exclude>
                            <exclude>META-INF/*.RSA</exclude>
                        </excludes>
                    </filter>
                </filters>
                <transformers>
                    <transformer
                        implementation="org.apache.maven.plugins.shade.resource.ManifestResourceTransformer">
                        <mainClass>io.metaloom.poc.server.ServerRunner</mainClass>
                    </transformer>
                    <transformer
                        implementation="org.apache.maven.plugins.shade.resource.ServicesResourceTransformer" />
                </transformers>
            </configuration>
        </execution>
    </executions>
</plugin>
…

The mainClass section references the ServerRunner in order to create the correct manifest in the jar file.

The server can be started after building the project using:

java -jar server/target/poc-vertx-dagger-server-1.0.0-SNAPSHOT.jar

Final words

The whole PoC sources can be found here https://github.com/metaloom/poc-vertx-dagger

Personally I prefer Dagger over Spring DI since it does not involve classpath scanning. One application I build a while ago was previously using Spring DI and had performance issues during startup since the JVM was busy scanning the rather large classpath for DI. I assume this could have been solved by using package prefixes for DI scanning but I switched to Dagger instead and I don’t regret the decision.

Dagger however can also sometimes be a bit picky. Previously I had issues with the generated code when using @Inject on public fields. Sometimes the generated constructor argument order would not match up and dagger was not happy. Additionally at least when using Eclipse IDE you sometimes need to re-compile/re-generate the dagger sources if you change DI related code. This may however be related to the m2e-apt plugin.

I hope you enjoyed this quick introduction. If you want to learn more about Dagger I can recommend the documentation.
