Day2 - Project Setup

blog-image
Credit: Photo by Terry Vlisidis on Unsplash

Disclaimer

  • Coke vs. Sprite

  • Ketchup vs. Majo

  • Eclipse vs. IntelliJ

  • Java vs. Kotlin vs. Rust

Almost 99% of the time there is no perfect solution to a problem. If someone asks me what tools I would recommend I tend to say to choose the tool that works best for you personally.

For the setup I’m going to describe my personal preference which is based on my own experience.

Setup

I’m using Apache Maven for my java project structure.

With maven you can create modules in which to split your project into different components.

Root POM

The root level of my project is called 'maven-parent'.

pom.xml
<groupId>io.metaloom</groupId>
<artifactId>maven-parent</artifactId>
<version>1.0.0-SNAPSHOT</version>
<packaging>pom</packaging>

All the maven projects under metaloom share this parent. This means all modules also inherit the properties and plugin definitions. I use this parent module to:

  • Define common maven repositories via repositories section.

  • Pin the maven plugin version via the pluginManagement section.

  • Pin very common maven dependency version (e.g. JUnit) via the dependencyManagement section.

Vert.x Root POM

pom.xml
<groupId>io.metaloom.vertx</groupId>
<artifactId>maven-vertx-parent</artifactId>
<version>1.0.0-SNAPSHOT</version>
<packaging>pom</packaging>

I use my maven-vertx-parent to pin and define Vert.x dependencies via the dependencyManagement section.

I think it is also possible to include a bom (BillOfMaterials POM) from Vert.x.

Loom Maven Modules

For Loom I decided to modularize as much as possible. I know that this can quickly result in dependency hell situations but I’d rather deal with dependency hell than spaghetti code.

While working on Mesh I made a few bad design decisions. For one I put REST API code, Domain model code and business logic in one core module. The api, rest-api, rest-modules and search integration and other parts were in dedicated modules but having everything in the core resulted in a lot of effort that was needed to isolate and refactor the database code. The situation was even worse since the domain model classes also contained most of the business logic.

For Loom I decided to create modules for each aspect of the application and move non-api code that needs to be shared across modules into the common module. The service modules can thus depend on this code in order to implement their functionality.

The core module aggregates all service modules and provides bundle that can be depended by the container modules which are used to generated the final executable shaded jar.

Model Overview:

Module Description

bom

Central BOM module which is imported in all modules to pin dependency versions

api

Module which contains public API code which nearly or no dependencies

common

Common module which contains shared code needed for various services

rest-model

REST Model definitions (mostly only POJO’s with jackson annotations)

rest-client

REST API client implementation

db

Central DB parent module

db/api

API module which defines the DAO interfaces and Domain Model interfaces

db/fs

Filesystem specific DAO implementation

db/flyway

Flyway database migration mechanism

db/jooq

jOOQ specific DAO implementation

db/memory

In-Memory specific DAO implementation

services

Services parent module

services/auth

Authentication services

services/auth/common

Common code for various SSO and auth implementations

services/auth/jwt

Basic JWT handling

services/auth/auth0

Auth0 SSO handling

services/auth/keycloak

Keycloak SSO handling

services/auth/auth-okta

Okta SSO handling

services/elasticsearch

Elasticsearch integeration (contains document transformation and search handling)

services/fs

Filesystem Asset storage code

services/image

Image processing code

services/monitoring

Monitoring code

services/rest

REST API implementation of OpenAPI spec

services/tika

Tika Asset processing

services/webhook

Webhook handling

services/distributed

Code to handle distributed clustering code

services/eventbus

Eventbus models and event handling

services/graphql

GraphQL type definitions

services/logger

Logging code

services/s3

S3 connector code

services/video

Video processing code

core

Central core module to combine all services

containers

Common container module

containers/demo

Maven module for building the demo container

containers/server

Maven module for building the server container

cli

Loom CLI

doc

Loom documentation and example generation

Recommendations

Use BOM POM

  • Use a dedicated BOM pom in your project to manage dependencies

First Define your bom module.

pom.xml
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
	xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">
	<modelVersion>4.0.0</modelVersion>

	<parent>
		<groupId>io.metaloom.loom</groupId>
		<artifactId>loom</artifactId>
		<version>1.0.0-SNAPSHOT</version>
	</parent>

	<artifactId>loom-bom</artifactId>
	<name>Loom - BOM</name>

	<dependencyManagement>
		<dependencies>
			<dependency>
				<groupId>commons-cli</groupId>
				<artifactId>commons-cli</artifactId>
				<version>1.4</version>
			</dependency>
			<dependency>
				<groupId>org.apache.commons</groupId>
				<artifactId>commons-lang3</artifactId>
				<version>3.12.0</version>
			</dependency>
			<dependency>
				<groupId>commons-io</groupId>
				<artifactId>commons-io</artifactId>
				<version>2.8.0</version>
			</dependency>
		</dependencies>
    </dependencyManagement>
</project>

Next import it in your project modules

pom.xml
<dependencyManagement>
    <dependencies>
        <dependency>
            <groupId>io.metaloom.loom</groupId>
            <artifactId>loom-bom</artifactId>
            <type>pom</type>
            <scope>import</scope>
            <version>${project.version}</version>
        </dependency>
    </dependencies>
</dependencyManagement>

Now you can add dependencies without defining the dep version. .pom.xml

<dependency>
    <groupId>commons-cli</groupId>
    <artifactId>commons-cli</artifactId>
</dependency>
Add your project dependencies to your bom pom. This way you can avoid <version>${project.version}</version>.

Modularize your application

It might be tempting to throw various components of your application in one module but that can turn out to be a problem when you need to refactor something.

For Loom I’ll place the interfaces into the common module. This way all services can access these and depend upon them.

The service implementations can now utilize the interfaces. When using dagger this is especially useful since you can create bindings for specific implementations. The services do not know which implementation they are using. Instead they just inject a dependency based on the interface. I’ll cover this in a dedicated post in which we’ll take a closer look on how I use dagger to manage dependency injection.
